| PHLTD 19 core thread connection parameter table | ||||||||
 |
||||||||
| Insertion method | Housing material | insulator | Contact material | protection grade | Connection | Number of insertions | temperature range | insulation resistance |
| threaded | Aluminum anodizing | PPS, Fire rating V-0, temperature resistance 260C | Copper (gold-plated) | IP66/67 | weld | 500 | ‘-40°C-+85°C | 2000 MQ |
| CORE | Rated current (A) | Contact diameter | working voltage | Voltage withstand (AC/V) Imin | Contact resistance (M Ω) | Wire gauge (mm ²/AWG) | Front view of the insulator at the male end | |
| 19 | 25 | Φ3 | 700(DC.V),500 (AC.V) | 2500 | 1 | ≤6/9 |  |
|
Enhanced Protection: The IP67 rating provides exceptional resilience, ensuring the socket operates seamlessly in damp, dusty conditions and even short-term submersion, significantly enhancing equipment reliability and lifespan.
Sturdy Construction: Made with an anodized aluminum shell, it resists wear and corrosion, making it durable enough to endure harsh environments.
Safety First: With PPS insulation rated V-0 for fire resistance and a high heat tolerance of up to 260°C, the gold-plated copper contacts ensure superior conductivity, preventing corrosion, resistance issues, and poor connections to improve electrical safety and stability.
Wide Temperature Range: Designed to perform reliably in temperatures from -40°C to +85°C, making it suitable for a variety of environments.
Effortless Installation & Maintenance: The threaded connection ensures a secure link between the socket and cables or other equipment, while making disassembly and maintenance easy and user-friendly.
Versatile Applications: With outstanding performance and reliability, this socket is widely used in industries such as industrial automation, solar energy, outdoor signage, oilfield equipment, and chemical installations.
